TWIN LEADING SHOE BRAKES A step by step guide to a super stopper. 1. Assemble all new parts likely to be needed before doing anything – usually shoes and cable. 2. Remove wheel and note relationship of cams, levers and springs before stripping back plate completely. If cam ends are not stamped with an alignment […]
Category: Brakes
T500 2LS brake set-up
It is imperative that the leading edge of each brake shoe comes into contact with the brake drum simultaneously, if maximum braking efficiency is to be achieved. Check by detaching the clevis pin from the eye of one end of the threaded rod, so that the brake operating arms can be applied independently. Operate each […]
How to setup a twin-leading-shoe brake
Borrowed from classicbike.com.uk – Not Suzuki but concept the same. also
